L Foot Bracket For Solar Tin Roof Mounitng System

L Feet Brackets For Tin Roof Solar Mounting, veay easy installation.
  • Item NO.:

    RS-TF-01
  • Payment:

    TT,LC
  • Product Origin:

    China
  • Color:

    silver
  • Shipping Port:

    Xiamen,China
  • Lead Time:

    15-20 working days
  • Product Detail

L Foot Bracket For Solar Tin Roof Mounitng Sytem

Solar First Solar Panel mounting brackets are very easy to use, can support RV Boat Off Grid Roof and Any Flat Surface.

The solar Mounting Brackets are Manufactured of High Quality Aluminum and Therefore are very Light Weight and Convenient.
The Solar Mounting Brackets can works for any solar panels. Can work with or without guide rail in on-grid and off-grid systems.
The hook can be used with either composite or metal roofs as well as with other manufacturers rail and flashed mounting systems.
Maintenance Free & Easy Installation.


Technical Specification

Mount type

     Solar First Tin Roof Mounting Brackets

Installation site

 Tin Roof

Structural materials

Aluminum alloy and stainless steel

Survival wind speed

60m/s

Design snow load

1.4KN/m2

System tilt angle

10-45°

Module orientation

Vertical or horizontal

Design standard

AS/NZS 170

Life

Design life is 25years, Qaultity assurance for 10years

Delivery time

With 20-30 days

Package

Carton, wooden pallet for solar mounting




leave a message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
